                           Part III – PHYSICS
                (New Syllabus )

Time Allowed : 3 Hours]                                     (English Version)                         [Maximum Marks:150
PART I
N.B.:       i)              Answer all the questions.
                ii)             Choose and write the correct answer.
                iii)            Each question carries one mark                                                                          30 X 1 = 30

1. Production of charges without actual contact is known as
a. electrostatic induction                          b.conduction            c.charging                                d. induction
2. The amount of work done in moving a 500mc charge between two points on an equipotential surface is y
a.zero                                                       b.positive                 c.negative                                d.infinitive
3. The Field at a point at a distance of an elelctric dipole is directly proportional to
a. 1/x2                                                      b.1/x3                       c.1/x4                                       d.1/x3/2
4. Action of points is used in -----------------
a. Capacitor                                             b.Vande graff                          c. Lightening arrester               d.both a & c
5. The field from a point charge at 2m distance is 400V/m Then at --------- field will be 100V/m
a.50cm                                                     b. 4cm                     c. 4m                                                       d. 1/5m
6. The unit of electric field
                 a. Nm2 C-1                                              b. H/m                     c. Ncm                                     d. N/C
7. Which of the following is a scalar
a.Drift velocity                                        b.Current density     c.current                                  d.Electric field
8. The unit of mobility number is
a. mV-1s-1                                                 b. m2V-1s-1              c.m2V-1s-3                               d. mV-1s-4
9. In which of the following substance current pass through easily
a. Quartz                                                  b.Mica                      c.Germanium                          d.Copper
10. According to Joule’s heating law  H =
a. I2t/V                                                      b. V2Rt                    c.VIt                                       d. IR2t
11. Nichrome is used as a heating element because it has
a.low resistivity                                       b.low melting point c.more resistivity                     d.more sigma
12. The expression for Biot savart law is dB =
a. m0Idl/4p r2                                           b. m0Idl sin q  /4p r2          c. m0Idl x`r/4p r2          d.m0Idl x` r/4p r3
13. The magnetic field at a distance x from the centre of a current carrying circular coil is proportional to
a. x2                                                         b.x3                                    c. 1/x2                            d.1/x3
14. The time period of particle in cyclotron does not depend on
a.magentic induction        b.current          c.velocity  of the particle          d.mass of the particle
15. To convert an galvanometer in to a voltmeter ---------resistance  to be connected in--------------
a.low , series                           b.low , parallel                    c.high , series                                d.high , parallel
16. Electro magnetic induction is not used in
a.Transformer                          b.Room heater                 c. AC dynamo                                  d. Choke coil
17. The angle between area and area vector is
a.p                                           b.p/2                                    c. 2p                                             d. 0
18. Lenz’z law based on the conservation of ----------------
a. charge                                  b. flux                                  c.momentum                                d.energy
19.The self inductance of a linear conductor is ----------
a.zero                                       b.infinitive                      c.veryhigh                        d.very low
20. Henry is nothing but
a. Vs/A                                    b. Wb/A                          c.Ws                                       d.all of these
21. Which of the following does not allow a.c to pass through
a.resistor                                  b.capacitor                       c. inductor                                       d.all of these
22. In an AC circuit
a.averge current is 0                b.square of current is 0 c.average powerloss is 0 d.Ö2times of I rms
23. Motor rule is otherwise known as
a.fleming left                           b.fleming right           c.maxwell right                     d. right palm
24. In an electromagnetic waves ,power is transmitted in
a.equal in both fields   b.perpendicular to both c.only electric field  d.only in magnetic field
25. Electormagnetic waves are ------------- waves
a transverse              b.longitudinal                          c.transverse or longitudinal   d.none of these
26. The idea of EM waves was first proved experimentally  by
a.Hertz                                     b.Maxwell           c.Farad                          d.Watt
27. ----------- confirmed the exsistance of EM waves
a.Hertz                       b.Maxwell             c.Farad                                      d.Watt
28. The Phase difference between electric and magnetic component in an EM wave is
a.p                           b.p/2                              c.2p                                     d. 0
29. The speed of EM waves in vacuum is
a. Öm 0 e0                             b. 1/Öm 0e0            c. Öm 0/e0                           d. Öe0 /m 0
30. Which of the following is an optical active substance
a.NaCl                      b.KCl                                     c.Na                          d.Cl

PART- II
N.B.: Answer any fifteen questions                                                                                    15X 3 = 45

31. Calculate current in a conductor if 6.25 X 1018 electrons flow in one second.
32. Calculate the resistance of a lamp rating 220 V and 1 A
33. How will you increase the current sensitivity of a galvanometer?
34. Explain how end rule is applied to find the polarity of a long solenoid
35. What is neutral temperature?
36. Nichrome is used as heating element. Comment on this
37. Draw the phase diagram of circuit with C only
38. Calculate the equation for current if the rms of current is 30 A at 50 Hz
39.Define Thomspm coefficient and write its unit.
40. Define Electromagnetic induction.
41. Define I rms
42. Give the conditions for clear interference bands.
43. Define drift velocity?
44. Define mobility?
45. State Ohm’s law?
46. Define Coulomb?
47. What is action of points?
48. When unpolarised light is incident on a medium of m = 1.732, calculate ip
49. Why does the sky appear blue in color?
50. What factors does optical rotation depend upon?


PART III

N.B.:       i)                Answer the Question No. 60 compulsorily
                ii)              Answer any six of the remaining 11 questions.
                iii)             Draw diagrams wherever necessary                                                  7X 5 = 35

51 Resistance of a coil at 200C is at 65 ohm  and at 500C is 70 ohm calculate temperature
     Coefficient of resistance.
52. Explain lens law on the conservation of energy
53.Write short notes on three phase generator
54. Explain the a.c circuit with resistance  only
55. Find rms of current in a circuit with a capacitor of capacitance 2microfaradwithfrequencyof 1000 Hz
     And the rms of voltage is 10 V
56. Write a note on Nichol prism.
57. The fringe width in Young’s expt with l = 5000 A is 0.6 cm. Find the new width if ‘D’ is halved.
58.Give the properties of electric lines of force.
59.Explain current  sensitivity of a galvanometer
60.A long solenoid of length 3m has 4000 turns. Find current through the solenoid if the B at centre is 8 X 10-3 T.
(OR)
      In a TG 1 A current produces a deflection of 30o .Find the current required to produce the deflection of 60o.
61. Give the principle of a capacitor.
62. Give Gauss law with any one application.

PART –IV

N.B.:       i)              Answer any four questions in detail
ii)             Draw diagrams wherever necessary                                                   4X 10 = 40

63. Deduce an expression for field at a point on its axial line of an electric dipole.
64. Deduce the relation for the magnetic induction at a point along the axis of a
      circular coil carrying current.
65. Write down the method of inducing emf  by changing the orientation of the coil.
66. Write a detailed note on LCR circuit with the help of the phaser diagram.
67. Deduce an expression for the capacity of a parallel plate capacitor with an dielectric?
68. With a neat diagram, explain the construction and working of an AC generator.
69.Derive an expression for b of interference fringes in Young’s experiment.
70.What are Newton’s rings? Find the radius of nth dark ring.
